October 20, 2019, 05:28:14 AM by tinhead | Views: 2729 | Comments: 7

Hello all,

Been a few years since I actually built a robot and since I have never really tried to build anything with legs here we go.

Here is the plan so far:

- 12 DOF using MG90S microservos
- rpi zero w as brainz
- PCA9685 16 channel pwm driver for the many servos
- custom built battery pack out of two 3.6v li-ion cells with BMS
- an ubec to provide the 5v
- sensors TBD

I have all the parts in stock for a while now which is cool :D

Software wise (still in planning):
- the pi will run a custom build linux image
- the control software will be spawned from an earlier project I've been playing with written in golang using a framework called gobot.io...
Killer Angel
October 14, 2019, 03:32:40 AM by Killer Angel
Views: 5397 | Comments: 7

v1

v2


I have started making a 2D Side Scroller game Cyberpunk themed.
The character, walls, ceiling and ladder are from the Warped City tileset (https://ansimuz.itch.io/warped-city).
The brick background wall is a darker version from a tutorial I have found (https://www.deviantart.com/makestuffhapen/art/Brick-wall-tutorial-334697091).

The hexagonal tiles, the door, cabinet, desk (with computer on top), bed and window are my own.

Differences between v1 and v2:
* changed background wall from bricks to hexagonal tiles
* changed door design
* changed locker design

I have been c...
James
September 01, 2019, 07:45:19 PM by James
Views: 3022 | Comments: 3


Current state of the MSD

The Motorized solder dispenser

They say necessity is the mother of invention. I can't say that this is an example of that, but it's 'extreme feature creep' at least.   ;D I have an RGB LED kit I hope to assemble that has a LOT of surface mount parts to solder. I plan to hand solder everything, one component value at a time, with some very small diameter solder. I was thinking about trying to hold the almost limp solder and not buggering everything up in the process. Then as I pondered that problem, I thought a little hand held solder dispenser must surely exist already, but a lot of googling tol...
Gareth
August 15, 2019, 06:16:37 AM by Gareth
Views: 2768 | Comments: 6


Needed an additional clock for my 2nd fallout shelter, electronics are now operational, so thought it best to share current iteration.

What you see here is the High voltage / opto isolator /  Nixie driver board.
Current Shopping list :-
  • ESP32
  • Batch of New Old Stock Cold War Nixies
  • NE555 timer chip to develop the High Tension voltage via a flyback inductor.
  • DS3231 Real Time
...
Gareth
August 06, 2019, 11:12:09 AM by Gareth
Views: 2845 | Comments: 2


Software defined radio (aka SDR), is a way of automating tuning into Audio/Digital radio receptions.

I am using a very simple (un-nervingly sensitive) USB dongle type RTL-SDR.COM

(cost inclusive antenna & mount was < £25).


This is able to tune through a huge spectrum of frequencies 0hz!! > 2.5Ghz

On a basic level it will tune into music radio station.....how ever where is the fun in that......

Also covers all the Radio Amateur bands , Dab radio and also Dab TV....etcetera

I am cu...
